What tracking down missing TCP Keepalives taught me about Docker, Golang, and GitLab

This blog post was originally published on the GitLab Unfiltered blog. It was reviewed and republished on 2019-12-03.

What began as failure in a GitLab static analysis check led to a

dizzying investigation that uncovered a subtle [bug in the Docker client

library code](https://github.com/docker/for-linux/issues/853) used by

the GitLab Runner. We ultimately worked around the problem by upgrading

the Go compiler, but in the process we uncovered an unexpected change in

the Go TCP keepalive defaults that fixed an issue with Docker and GitLab

CI.

This investigation started on October 23, when backend engineer [Luke

Duncalfe](/company/team/#.luke) mentioned, "I'm seeing

static-analysis failures with no output.

Is there something wrong with this job?" He opened [a GitLab

issue](https://gitlab.com/gitlab-org/gitlab/issues/34951) to discuss.

When Luke ran the static analysis check locally on his laptop, he saw

useful debugging output when the test failed. For example, an extraneous

newline would accurately be reported by Rubocop. However, when the same

test ran in GitLab's automated test infrastructure, the test failed

quietly:

{: .shadow.center}

Notice how the job log did not include any clues after the `bin/rake

lint:all` step. This made it difficult to determine whether a real

problem existed, or whether this was just a flaky test.

In the ensuing days, numerous team members reported the same problem.

Nothing kills productivity like silent test failures.

Was something wrong with the test itself?

In the past, we had seen that if that specific test generated enough

errors, [the output buffer would fill up, and the continuous integration

(CI) job would lock

indefinitely](https://gitlab.com/gitlab-org/gitlab-foss/issues/61432). We

thought we had [fixed that issue months

ago](https://gitlab.com/gitlab-org/gitlab-foss/merge_requests/28402). Upon

further review, that fix seemed to eliminate any chance of a thread

deadlock.

Did we have to flush the buffer? No, because the Linux kernel will do

that for an exiting process already.

Was there a change in how CI logs were handled?

When a test runs in GitLab CI, the [GitLab

Runner](https://gitlab.com/gitlab-org/gitlab-runner/) launches a Docker

container that runs commands specified by a .gitlab-ci.yml inside the

project repository. As the job runs, the runner streams the output to

the GitLab API via PATCH requests. The GitLab backend saves this data

into a file. The following sequence diagram shows how this works:

== Get a job! ==

Runner -> GitLab: POST /api/v4/jobs/request

GitLab -> Runner: 201 Job was scheduled


== Job sends logs (1 of 2) ==

Runner -> GitLab: PATCH /api/v4/job/:id/trace

GitLab -> File: Save to disk

GitLab -> Runner: 202 Accepted


== Job sends logs (2 of 2) ==

Runner -> GitLab: PATCH /api/v4/job/:id/trace

GitLab -> File: Save to disk

GitLab -> Runner: 202 Accepted

Henrich Lee Yu mentioned

that we had recently [disabled a feature flag that changed how GitLab

handled CI job

logs](https://docs.gitlab.com/ee/administration/job_logs.html#new-incremental-logging-architecture). [The

timing seemed to line

up](https://gitlab.com/gitlab-org/gitlab/issues/34951#note_236723888).

This feature, called live CI traces, eliminates the need for a shared

POSIX filesystem (e.g., NFS) when saving job logs to disk by:

1. Streaming data into memory via Redis

2. Persisting the data in the database (PostgreSQL)

3. Archiving the final data into object storage

When this flag is enabled, the flow of CI job logs looks something like

the following:

== Get a job! ==

Runner -> GitLab: POST /api/v4/jobs/request

GitLab -> Runner: 201 Job was scheduled


== Job sends logs ==

Runner -> GitLab: PATCH /api/v4/job/:id/trace

GitLab -> Redis: Save chunk

GitLab -> Runner: 202 Accepted

...

== Copy 128 KB chunks from Redis to database ==

GitLab -> Redis: GET gitlab:ci:trace:id:chunks:0

GitLab -> PostgreSQL: INSERT INTO ci_build_trace_chunks

...

== Job finishes ==


Runner -> GitLab: PUT /api/v4/job/:id

GitLab -> Runner: 200 Job was updated


== Archive trace to object storage ==

Looking at the flow diagram above, we see that this approach has more

steps. After receiving data from the runner, something could have gone

wrong with handling a chunk of data. However, we still had many

questions:

1. Did the runners send the right data in the first place?

2. Did GitLab drop a chunk of data somewhere?

3. Did this new feature actually have anything to do with the problem?

4. Are they really making another Gremlins movie?

Reproducing the bug: Simplify the .gitlab-ci.yml

To help answer those questions, we simplified the .gitlab-ci.yml to

run only the static-analysis step. We inserted a known Rubocop error,

replacing a eq with eql. We first ran this test on a separate GitLab

instance with a private runner. No luck there – the job showed the right

output:

Offenses:


ee/spec/models/project_spec.rb:55:42: C: RSpec/BeEql: Prefer be over eql.
        expect(described_class.count).to eql(2)
                                         ^^^

12669 files inspected, 1 offense detected

However, we repeated the test on our staging server and found that we

reproduced the original problem. In addition, the live CI trace feature

flag had been activated on staging. Since the problem occurred with and

without the feature, we could eliminate that feature as a possible

cause.

Perhaps something with the GitLab server environment caused a

problem. For example, could the load balancers be rate-limiting the

runners? As an experiment, we pointed a private runner at the staging

server and re-ran the test. This time, it succeeded: the output was

shown. That seemed to suggest that the problem had more to do with the

runner than with the server.

Docker Machine vs. Docker

One key difference between the two tests: One runner used a shared,

autoscaled runner using a [Docker

Machine](https://docs.docker.com/machine/overview/) executor, and the

private runner used a [Docker

executor](https://docs.gitlab.com/runner/executors/docker.html).

What does Docker Machine do exactly? The following diagram may help

illustrate:

{: .medium.center}

The top-left shows a local Docker instance. When you run Docker from the

command-line interface (e.g., docker attach my-container), the program

just makes [REST calls to the Docker Engine

API](https://docs.docker.com/engine/api/v1.40/).

The rest of the diagram shows how Docker Machine fits into the

picture. Docker Machine is an entirely separate program. The GitLab

Runner shells out to docker-machine to create and destroy virtual

machines using cloud-specific (e.g. Amazon, Google, etc.) drivers. Once

a machine is running, the runner then uses the Docker Engine API to run,

watch, and stop containers.

Note that this API is used securely over an HTTPS connection. This is an

important difference between the Docker Machine executor and Docker

executor: The former needs to communicate across the network, while the

latter can either use a local TCP socket or UNIX domain socket.

Google Cloud Platform timeouts

We've known for a while that Google Cloud [has a 10-minute idle

timeout](https://cloud.google.com/compute/docs/troubleshooting/general-tips),

which has caused issues in the past:

Note that idle connections are tracked for a maximum of 10 minutes,

after which their traffic is subject to firewall rules, including the

implied deny ingress rule. If your instance initiates or accepts

long-lived connections with an external host, you should adjust TCP

keep-alive settings on your Compute Engine instances to less than 600

seconds to ensure that connections are refreshed before the timeout

occurs.

Was the problem caused by this timeout? With the Docker Machine

executor, we found that we could reproduce the problem with a simple

.gitlab-ci.yml:

image: "busybox:latest"


test:
  script:
    - date
    - sleep 601
    - echo "Hello world!"
    - date
    - exit 1

This would reproduce the failure, where we would never see the `Hello

world!output. Changing thesleep 601tosleep 599` would make the

problem go away. Hurrah! All we have to do is tweak the system TCP

keepalives, right? Google provided these sensible settings:

sudo /sbin/sysctl -w net.ipv4.tcp_keepalive_time=60
net.ipv4.tcp_keepalive_intvl=60 net.ipv4.tcp_keepalive_probes=5

However, enabling these kernel-level settings didn't solve the

problem. Were keepalives even being sent? Or was there some other issue?

We turned our attention to network traces.

Eavesdropping on Docker traffic

In order to understand what was happening, we needed to be able to

monitor the network communication between the runner and the Docker

container. But how exactly does the GitLab Runner stream data from a

Docker container to the GitLab server? The following diagram

illustrates the flow:

Runner -> Docker: POST /containers/name/attach

Docker -> Runner: <container output>

Docker -> Runner: <container output>

Runner -> GitLab: PATCH /api/v4/job/:id/trace

GitLab -> File: Save to disk

GitLab -> Runner: 202 Accepted

First, the runner makes a [POST request to attach to the container

output](https://docs.docker.com/engine/api/v1.40/#operation/ContainerAttach).

As soon as a process running in the container outputs some data, Docker

will transmit the data over this HTTPS stream. The runner then copies

this data to GitLab via the PATCH request.

However, as mentioned earlier, traffic between a GitLab Runner and the

remote Docker machine is encrypted over HTTPS on port 2376. Was there an

easy way to disable HTTPS? Searching through the code of Docker Machine,

we found that it did not appear to be supported out of the box.

Since we couldn't disable HTTPS, we had two ways to eavesdrop:

1. Use a man-in-the-middle proxy (e.g. mitmproxy)

2. Record the traffic and decrypt the traffic later using the private keys

Ok, let's be the man-in-the-middle!

The first seemed more straightforward, since [we already had experience

doing this with the Docker

client](https://docs.gitlab.com/ee/administration/packages/container_registry.html#running-the-docker-daemon-with-a-proxy).

However, after [defining the proxy variables for GitLab

Runner](https://docs.gitlab.com/runner/configuration/proxy.html#adding-proxy-variables-to-the-runner-config),

we found we were only able to intercept the GitLab API calls with

mitmproxy. The Docker API calls still went directly to the remote

host. Something wasn't obeying the proxy configuration, but we didn't

investigate further. We tried the second approach.

Decrypting TLS data

To decrypt TLS data, we would need to obtain the encryption keys. Where

were these located for a newly-created system with docker-machine? It

turns out docker-machine worked in the following way:

1. Call the Google Cloud API to create a new machine

2. Create a /root/.docker/machine/machines/:machine_name directory

3. Generate a new SSH keypair

4. Install the SSH key on the server

5. Generate a new TLS certificate and key

6. Install and configure Docker on the newly-created machine with TLS certificates

As long as the machine runs, the directory will contain the information

needed to decode this traffic. We ran tcpdump and saved the private keys.

Our first attempt at decoding the traffic failed. Wireshark could not

decode the encrypted traffic, although general TCP traffic could still

be seen. Researching more, we found out why: If the encrypted traffic

used a [Diffie-Hellman key

exchange](https://en.wikipedia.org/wiki/Diffie%E2%80%93Hellman_key_exchange),

having the private keys would not suffice! This is by design, a property

called [perfect forward

secrecy](https://en.m.wikipedia.org/wiki/Forward_secrecy).

To get around that limitation, we modified the GitLab Runner to disable

cipher suites that used the Diffie-Hellman key exchange:

diff --git
a/vendor/github.com/docker/go-connections/tlsconfig/config_client_ciphers.go
b/vendor/github.com/docker/go-connections/tlsconfig/config_client_ciphers.go

index 6b4c6a7c0..a3f86d756 100644
